ADS took a look at one of the issues that continues to face deployed troops; access to C4ISR feeds. They assembled a team of industry partners including Granite Tactical Vehicles, FLIR, Harris and SYNEXXUS to create a C4ISR Vehicle Concept Demonstrator.
Using COTS items, this team has been able to streamline the way Command, Control, Communications, Computers, Intelligence, Surveillance and and Reconnaissance data is delivered and displayed to the personnel in the vehicle. It’s now easier to see, interpret and share.
FLIR offers these enhancements to the Demonstrator:
FLIR Systems DV/SA provides Driver Visual Enhancement and Situational Awareness has been used on both wheeled and tracked platforms. It offers the following suite of options:
• Dual Sensor with both thermal and day cameras (enabling blending)
• Single Sensor with thermal camera.
• Cameras with motorized protective lid and cleaning brush.
• 55 degree field of view for increased performance.
• 90 degree field of view for wide angle situational awareness.
FLIR Systems TALON:
• High-performance multi-sensor thermal imaging system in a compact, lightweight 9” package.
• This system offers up to six simultaneous payloads including: IR, Color, CCD, EMCCD, Laser Pointer or Laser Illuminator, LRF and IMU.
• The FLIR Systems TALON offers operators a continuous zoom 640 x 480 infrared IR camera and 2 EO options (color and color/ EMCCD combination) which permit high resolution imagery both day and night
Harris is well known for providing communications systems and the C4ISR Vehicle Concept Demonstrator is no different with the integration of the AN/PRC-117G.
• JTRS Certified, NSA Type-1 Certified, JITC Certified for Narrowband Interoperability Assessment and compliance with DAMA standards
• Includes SINCGARS, Havequick II, VHF/UHF AM and FM, High Performance Waveform (HPW), MIL-STD-188-181B SATCOM.
• Uses the Harris Adaptive Networking Wideband Waveform (ANW2) for high bandwidth data operation and is designed for future upgrade to the Soldier Radio Waveform (SRW)
If FLIR is the eyes of the system and Harris the ears, SYNEXXUS provides the central nervous system.
The ELECTRONIC KEEL® V5.3 is a modular, data/video distribution architecture, designed for rugged reliability with open standard industry inputs. The EKEEL’s open operating system and open published API and GUI software provide the operator with access to platform sensors, radios, applications and other government furnished equipment (GFE) or customer furnished equipment (CFE) with single button actuation and intuitive interface. All platform sub-systems are able to be viewed, controlled and shared from a single interface through one or more independently controlled and simultaneously viewed resistive-touch, multi-function displays. Any government provided software and applications can be used in conjunction with or as an alternative to the system’s software suite.
• Combat-Proven, TRL-9 Rated Digital Backbone
• Operationally Deployed in Theater Since 2009
• Modular, Open Hardware and Software Interfaces
• Access, Control and Network All Platform GFE, Apps and Systems
• Increased Situational Awareness, Decreased SWaP
In this ADStv video, representatives from each of the vendors discuss the capabilities they bring to this project.
With the integration of these different, yet complimentary, capabilities into an upgraded, armored vehicle platform, the ADS C4ISR Vehicle Concept Demonstrator has shown a system that doesn’t suffer from the band-aid fixes that have plagued the legacy HMMWV program over the years. The interior is streamlined and future capabilities can more easily be integrated into the architecture. This is certainly a viable path forward to refit the existing HMMWV fleet with new capabilities.
For more information visit www.ADSinc.com.
